Text display
131
1SVC 440 795 M0100
Text display CL-LSR/CL-LST and CL-LMR/CL-LMT are able to display 16
freely editable texts. These texts can be triggered by the
actual values of function relays such as timing relays,
counters, operating hours counters, analog value
comparators, date, time or scaled analog values. The
setpoints of timing relays, counters, operating hours
counters, analog value comparators can be modified when
the text is displayed. The text display can only be edited with
CL-SOFT (from Version 6.xx). The texts are stored in the
CL-SOFT file or on the CL-LAS.MD003 memory module for
CL-LSR/CL-LST and CL-LMR/CL-LMT.
Parameter settings of the counter C14
Parameter setting of analog value comparators A1 and A2
Parameter settings A3
C 14 H+
S +0
A1 LT +
I1 C
13 Æ
F1 +0
I2 C
14 æ
F2 +0
OS +0
HY 0015
A2 LT +
I1 C
14 Æ
F1 +0
I2 C
13 æ
F2 +0
OS +0
HY 0015
A1 EQ +
I1 C
13 Æ
F1 +0
I2 C14 æ
F2 +0
OS +0
HY 0020
