Text display
133
1SVC 440 795 M0100
Example of a text display:
The text display can display the following:
Scaling
The values of the analog inputs can be scaled.
Function
The D text output function block (D = Display, tex t display)
operates in the circuit diagram like a normal M marker. If a
text is assigned to a marker, this is displayed in the CL
display when the coil is set to 1. For this to take place, the
logic relay must be in RUN mode and the status display must
be activated before the text is displayed.
D2 to D16:
If several texts are present and are triggered, each text is
automatically displayed in turn every 4 s. This process will be
repeated until
• No other text display function block is set to 1.
• STOP mode is selected.
SWITCH;
CONTROL;
DISPLAYS;
MADE EASY!
Line 1, 12 characters
Line 2, 12 characters, a setpoint or actual value
Line 3, 12 characters, a setpoint or actual value
Line 4, 12 characters
RUNTIME M:S
T1 :012:46
C1 :0355 ST
PRODUCED
Range Selectable display
range
Example
10 to +10 V 0 to 9999 0000 to 0100
10 to +10 V g 999 –025 to 050
10 to +10 V g 9.9 –5.0 to 5.0
