Device version
245
1SVC 440 795 M0100
The display modules CL-LDD.XK (IP65) and CL-LDD.K (IP65)
with the CL-LDC.S... remote display connection modules are
currently available for use as stand-alone display modules.
Device version Every logic relay has the device version number printed on
the left of the device housing. The device version is indicated
by the first two digits of the device number.
Figure 92: Example of device version
This device is of device version 01.
The device version provides useful service information about
the hardware version and the version of the operating
system.The device version is important for selecting the
correct logic relay for CL-SOFT.
h
The remote display connection module CL-LDC.S...
communicates continuously with the logic relay. This
increases the cycle time of the logic relay and must be
taken into account during engineering.
DC 20,4 …28,8 V
3 W
01-900000042
