Counters
111
1SVC 440 795 M0100
Counters The logic relay provides 16 up/down counters C1 to C16 for
use as required. The counter relays allow you to count
events. You can define an upper threshold value as a
comparison value. The contact will switch according to the
actual value.
High-speed counters, frequency counters up to 1 kHz
counter frequency.
CL-DC1 and CL-DC2 feature four high-speed counters C13 to
C16. The function is defined by the mode selected. The
counter input is connected directly to a digital input. The
high-speed digital inputs are I1 to I4.
Possible applications include the counting of components,
lengths, events and frequency measurement.
Table 11: Counter modes
h
The counters of CL-LSR/CL-LST and CL-LMR/CL-LMT
function in the same way as the counters of the AC010
devices. If required, the same counters can also be used
for retentive data.
Counters Operating
mode
C1 to C12 N Up/down counter
C13, C14
N or H Up/down counters or
high-speed up counters
(CL-DC1, CL-DC2)
C15, C16
N or F Up/down counters or
frequency counters
(CL-DC1, CL-DC2)
