CL settings
204
1SVC 440 795 M0100
The parameter set for the time switch function relay 1 is
saved in channel A and looks like this.
From the following weekend, the outdoor lighting is now
also required to switch on between 19:00 and 22:00 on
Saturdays.
X Select PARAMETER from the main menu.
The first parameter set is displayed.
X Use Í or Ú to scroll through the parameter sets until
channel A of time switch 1 is displayed.
X Press Í to select the next empty parameter set, in this
case channel B of time switch 1.
The current time is 11:30.
X Change the value for the day interval from MO to SA:
–
úí Move between the parameters
– ÍÚ Change value.
X Press OK to acknowledge the value SA.
X Change the ON value to 19:00.
X Move to the value of ON
X Press OK.
–
úí Move between the parameters
– ÍÚ Change value.
X Press OK to acknowledge the value 19:00.
X Set the switching off time to 22:00.
X Press OK.
The logic relay will save the new parameters. The cursor will
remain in the contact field on channel identifier B.
Press ESC to leave the parameter display.
The time switch will now also switch on at 19:00 on
Saturdays and switch off at 22:00.
Ö1 A 11:30 +
D MO-FR
ON 19:00
OFF 23:30
Ö1 B 11:30 +
D --
ON 00:00
OFF 00:00
Ö1 B 11:30 +
D SA
ON 00:00
OFF 00:00
Ö1 B 11:30 +
D SA
ON 19:00
OFF 00:00
Ö1 B 11:30 +
D SA
ON 19:00
OFF 22:00
