EL3000 CONTINUOUS GAS ANALYZERS | OI/EL3000-EN REV. D 47
Uras26: Gas connections for pipelines
(internal gas lines made stainless steel pipes)
Pos.
Connection
Supplementary information
Version
6
Pressure sensor
—
Screwed connections with hose nozzles (stainless
steel
1.4305) for hoses with 4 mm inside diameter
(included in scope of supply)
11
Sample gas inlet
—
⅛ NPT female thread (stainless steel 1.4305) for
threaded connections
(not included in scope of supply
)
12
Sample gas outlet
For a sample cell
13
Sample gas outlet
For two sample cells in series
Note
The oxygen sensor, the ‘integrated gas feed’ option and the version with separated gas paths are not possible.
