ABB EasyLine EL3000 User Manual

60 EL3000 CONTINUOUS GAS ANALYZERS | OI/EL3000-EN REV. D
… 5 Installation
… Position and design of the gas connections
Caldos27: Gas Connections
Pos.
Connection
Supplementary information
Version
1
Sample gas inlet
—
⅛ NPT female thread (stainless steel 1.4305)
•
Connection of hose lines:
straight screw-
in socket (PP) with hose nozzles
for hoses with inside diameter 4 mm
(included in scope of delivery)
•
Connection of piping:
screw-in fittings
(not included in scope of delivery)
2
Sample gas outlet
—
3
not used
—
4
not used
—
Note
The sample gas inlet of Caldos27 can be connected to the sample gas output (gas path 1) of Uras26 at the factory or have a separate
sample gas path without connection to Uras26.
