ABB EasyLine EL3000 User Manual

74 EL3000 CONTINUOUS GAS ANALYZERS | OI/EL3000-EN REV. D
… 5 Installation
… Position and design of the gas connections
Magnos28 with Caldos27 – gas connections for ‘Integral gas feed’ option with flow sensor
Pos.
Connection
Supplementary information
Version
1
Sample gas outlet
(gas path 1 / Magnos28)
Factory-connected to Magnos28 sample gas inlet 1
Screwed connections with hose
nozzles (stainless
steel
1.4305) for hoses with 4 mm inside diameter
(included in scope of supply)
2
Sample gas inlet
(gas path
1 / Magnos28)
—
3
Sample gas outlet
(gas path 2 / Caldos27)
Factory-connected to Caldos27 sample gas inlet 1
4
Sample
gas inlet
(gas path
2 / Caldos27)
—
5
Pressure sensor
For Caldos27
6
Pressure sensor (option)
For Magnos28
