Calibration of the Uras26 with internal cross-sensitivity correction
Possible electronic cross-sensitivity corrections by other sample compo-
nents measured by Uras26 are disabled for the calculation of the calibration.
The following information should therefore be noted in particular:
Zero-point calibration
All the sample components must always be calibrated in the following se-
quence for the zero-point calibration:
• firstly the sample component which is not corrected,
• then the sample component which is affected by the smallest number of
corrections,
• up to the sample component which is affected by the largest number of
corrections.
End-point calibration
All the sample components must also always be calibrated in the end-point
calibration. Here, a corrected sample component may only be calibrated
using a test gas which does not contain any components which cause
cross-sensitivity, i.e. which only consists of the sample component and an
inert gas, e.g. N
2
.
Test gases
Analyzer Test gas for zero-point calibration Test gas for end-point calibration
Uras26 with calibration cells
(automatic calibration)
N
2
or air or IR sample component-free
gas
– (calibration cells)
Uras26 without calibration
cells (automatic calibration)
N
2
or air Span gas*
Uras26 without calibration
cells (manual calibration)
N
2
or air Test gas for each sample component
or for each detector
Uras26 + Magnos206
(automatic calibration,
i.e. Magnos206 with
single-point calibration)
IR sample component-free test gas
with O
2
concentration in an existing
measuring range or ambient air.
Same moisture content as process
gas.
Calibration cells or span gas*
Uras26 + Magnos206
(manual calibration)
Zero reference gas for Uras26 or
Magnos206, or IR sample component-
free test gas with O
2
concentration in
an existing measuring range or am-
bient air. Same moisture content as
process gas.
Span gas for all sample components
in the Uras26 and Magnos206 (possi-
bly only for the Uras26 if a single-
point calibration is carried out for the
Magnos206)
