90 EL3060 CONTINUOUS GAS ANALYZERS | OI/EL3060-EN REV. A
Low pass time constant configuration
Configuration
The low pass time constants can only be set in the configurator (see page
53) and not in the gas analyzer.
Parameters
A non-linear filter with 2 low pass time constants and a switching threshold
can be configured for each sample component:
Low-pass time constant Value range: 0 to 60 s
Low-pass time constant
for non-linear filter
Value range: 0 to 60 s
Switching threshold
for non-linear filter
Value range: 0 to 9.99 % of the physical measur-
ing range. If the threshold is crossed, the low
pass time constant for non-linear filter will be
activated.
