232 EtherNet/IP – Communication protocol
Instance #3: FENA-01/-11/-21 configuration parameters
group C (group 3)
The actual parameter group number depends on the drive type.
Group C (group 3) corresponds to:
• parameter group 54 in ACS355
• parameter group 52 in ACSM1, ACS850 and ACQ810
• parameter group 52 in ACS880 and ACS580 if the adapter is
installed as fieldbus adapter A or group 55 if the adapter is
installed as fieldbus adapter B.
# Attribute name Services Description Data
type
1 Configuration Group C
(Group 3) - Parameter 1
Get, Set See 01 DATA IN 1
on page 131.
UINT16
2 Configuration Group C
(Group 3) - Parameter 2
Get, Set See 01 DATA IN 1
on page 131.
UINT16
3 Configuration Group C
(Group 3) - Parameter 3
Get, Set See 01 DATA IN 1
on page 131.
UINT16
4 Configuration Group C
(Group 3) - Parameter 4
Get, Set See 01 DATA IN 1
on page 131.
UINT16
5 Configuration Group C
(Group 3) - Parameter 5
Get, Set See 01 DATA IN 1
on page 131.
UINT16
6 Configuration Group C
(Group 3) - Parameter 6
Get, Set See 01 DATA IN 1
on page 131.
UINT16
7 Configuration Group C
(Group 3) - Parameter 7
Get, Set See 01 DATA IN 1
on page 131.
UINT16
8 Configuration Group C
(Group 3) - Parameter 8
Get, Set See 01 DATA IN 1
on page 131.
UINT16
9 Configuration Group C
(Group 3) - Parameter 9
Get, Set See 01 DATA IN 1
on page 131.
UINT16
10 Configuration Group C
(Group 3) - Parameter
10
Get, Set See 01 DATA IN 1
on page 131.
UINT16

ABB FENA-21 Specifications

General

Product Type	Fieldbus Adapter
Supply voltage	24 V DC
Degree of protection	IP20
Type	FENA-21
Model	FENA-21
Manufacturer	ABB
Fieldbus protocol	EtherNet/IP
