1 Description
1.3.3 Mounting the manipulator
3HAC9117-1 Rev.N 23
Figure 10 Hole configuration (dimensions in mm).
Pos Description
A Z = center line axis 1
B The same dimensions
C View from the bottom of the base
D Section
