1 Description
1.3.3 Mounting the manipulator
24 Rev.N 3HAC9117-1
Mounting surface and bushings
Figure 11 Mounting surface and bushings.
Pos Description
A Surface treatment, ISO 2081 Fe/Zn 8 c2
Guide Bushings
B Common zone
