Navigator 500
Sodium analyzer 10 Specification – transmitter
70 OI/ASO550–EN Rev. G
10 Specification – transmitter
Operation
Display
89 mm (3.5 in) color 1/4 VGA TFT, liquid crystal display (LCD) with
built-in backlight and brightness / contrast adjustment
Language
English, German, French, Italian, Spanish
Keypad
6 tactile membrane keys:
Group select / left cursor, view select / right cursor, menu key,
up, down, enter key
No of inputs
Up to 4 single-stream or 1 multi-stream wet-section
Mechanical data
Protection
IP66 / NEMA 4X
Dimensions
Height – 194 mm (7.64 in) minimum (excluding glands)
Width – 214 mm (8.42 in) – excluding glands
Depth – 98 mm (3.85 in) door closed – minimum (excluding fixing
brackets)
Weight – 1.5 kg (3.3 lb)
Materials of construction
Glass-filled polycarbonate
Security
Password protection
Calibrate and Advanced – user-assigned
Service level access – factory-set
Electrical
Power supply ranges
100 to 240 V AC max., 50 / 60 Hz ± 10 %
(90 to 264 V AC, 45/65 Hz)
Power consumption
<10W
Terminal connections rating
AWG 26 to 16 (0.14 to 1.5 mm
2
)
Analog outputs
2 standard
2 optional
Galvanically isolated from the rest of the circuitry, 500 V for 1 minute.
Range-programmable source and range 0 to 22 mA, maximum
load 750 @ 20 mA
Relay outputs
4 standard
2 optional
Fully-programmable. Contacts rated at 2A @ 110 / 240 V. Standard
relays are changeover. Optional relays are normally closed (N/C).
Digital inputs / outputs
6 standard, user-programmable as input or output
Minimum input pulse duration: 125 ms
Input – volt-free or 24 VDC (conforms to IEC 61131-2)
Output – open-collector, 30 V, 100 mA max.
(conforms to IEC 61131-2)
Connectivity / communications
Ethernet (optional)
TCP/IP, HTTP
Data logging
Storage
Measurement value storage (programmable sample rate)
Audit Log*, Alarm Log*, Calibration log, Diagnostics log,
Configuration changes
Chart view
On local display
Historical review
Of data
Data transfer
Secure digital (SD) card interface / USB stick – Windows-compatible
FAT file system, data and log files in Excel and DataManager Pro
compatible formats
*Audit Log and Alarm Log data are stored in the same log file.
DS/ASO550–EN Rev. F
