Manual Power Quality Filter PQFS  Commissioning instructions 141

—

8 Commissioning instructions

8.1 What this chapter contains

This chapter presents the steps to follow to commission the active filter. The

commissioning of your PQF should be conducted in strict accordance with this

procedure.

Before applying the commissioning procedure, make sure that you are familiar with:

− The filter hardware (discussed in Chapter 4

− The mechanical installation requirements (discussed in Chapter 5).

− The electrical installation requirements (discussed in Chapter 6).

− The PQF programming interface PQF-Manager (discussed in Chapter 7).

− If the Modbus option has been installed, please refer to the document

“2GCS212013A0050-RS-485 Installation and Start-up guide” for more information

on this item.

The commissioning procedure consists of 9 steps that should be strictly followed.

Table 52: Steps to follow to commission the active filter

Steps

Actions

Step 1

Visual and installation check

Step 2 Setting the address of each unit in a multi-unit filter and terminate the CAN

bus

Step 3

Voltage rating and phase rotation check

Step 4 Basic commissioning parameters setup

Step 5 Automatic and manual CT detection procedure

Step 6

Before starting the filter

Step 7

Start the filter

Step 8

Generate filter load

Step 9 Set up the user requirements

Section 8.11 presents the commissioning report to be filled in when commissioning the

filter.

ABB PQFS User Manual
