160 Commissioning instructions  Manual Power Quality Filter PQFS
Project:
LV Active Filters PQF
Issued by:
Commissioning report
Date:
Page 1 of 7
8.11.1 Filter identification
Active filter type
(a)
Global ratings
(a)
Maximum voltage (V)
Total current (A)
System serial number
(a)
Filter connection mode (3-W or
4-W)
Unit ratings/serial number
(b)
Rating (A)
Serial number
Article code
(b)
Unit 1 (M)
Unit 2
(M/S)
(d)
Unit 3(M/S)
(d)
Unit 4(M/S)
(d)
Software version
(c)
PQF-Manager software
µcontroller software
DSP software
Installation location
Remarks:
(a)
Read from main identification tag located on the master enclosure.
(b)
Read on identification tag located at the outside of each enclosure.
(c)
After the filter has been commissioned, navigate with the PQF-Manager to [/Welcome/User
interface/About PQF].
(d)
Select whether this unit is a master (M) or a slave (S) unit.
