ABB PVS300 User Manual

114 Technical data
AC Output data and grid requirements
Surge protection device type (SPD) ABB, OVR PV 40 1000 P TS or Phoenix Contact, Type
VAL-MS 1000DC/2+V-FM-UD
Solar string fault current protection Solar string fuse, 10x38mm, 1000 VDC
All input terminals, monitored
Tested and approved solar string fuse
types
Cooper Bussmann, PV-1…20A10F, 1000 VDC
and
Ferraz Shawmut, PV Fuse HP10M1…20A, 1000 VDC
Solar string fuse nominal current
rating
12 A
Type Cooper Bussmann PV-12A10F included to
inverter
Solar string fuse maximum allowed
nominal current rating
20 A
DC switch load breaking capacity 25 A at 1000 VDC (DC21B)
Overvoltage category OVC II
Source: 3AXD00000593935, 3AXD10000042487
Inverter type PVS300-TL- 3300W-2 4000W-2 4600W-2 6000W-2 8000W-2
Nominal power 3300 W 4000 W 4600 W 6000 W 8000 W
Nominal current 14.3 A 17.4 A 20.0 A 26.1 A 34.8 A
Maximum current 15.6 A 18.9 A 21.7 A 28.3 A 37.7 A
Nominal grid connection 1/N/PE AC 230 V 50/60 Hz
Grid earthing systems supported TN-S, TN-C, TN-CS, and TT
See Common grid type configurations on page 43.
Operating voltage range 180…276 V,
range adjusted specifically for each country setting
Operating frequency range 47…63 Hz,
range adjusted specifically for each country setting
Harmonic distortion of grid current < 3%
Power factor 1
Protection class Class 1
Overvoltage category OVC III
Night consumption <1 W
Transformer type N/A, no transformer
Grid monitoring Automatic grid relays, DC and AC sensitive residual
current monitoring unit, anti-islanding functions
according to IEC and VDE standards
AC Connector type Fixed plug, 3pole+PE, Phoenix Contact Variocon
Power
AC connector ratings Maximum conductor size 16 mm2,
Maximum current 70 A,
Maximum voltage 690 V
Inverter type PVS300-TL- 3300W-2 4000W-2 4600W-2 6000W-2 8000W-2
