116 Technical data
Mechanical data
User interface and communication data
Performance data
The PVS300 inverters efficiency testing is performed by applying standard EN 50530,
Overall efficiency of grid connected photovoltaic inverter.
Inverter type PVS300-TL- 3300W-2 4000W-2 4600W-2 6000W-2 8000W-2
Inverter dimensions
Width / Height / Depth
W 392 / H 581 / D 242 mm
Inverter weight 27 kg 29 kg
Package dimensions
Width / Height / Depth
W 470 / H 700 / D 295 mm
Package weight 30 kg 32 kg
Installation clearances
Top / Sides / Bottom
T 250 / S 250 / B 500 mm
Source: 3AXD00000593935, 3AXD10000042487
Inverter type PVS300-TL- 3300W-2 4000W-2 4600W-2 6000W-2 8000W-2
Control unit type PVS-AP
Graphical, detachable
Control unit fixed mounting type PVS-APK-F,
optional accessory including surface and flush
mounting frames
Control unit mobile mounting type PVS-APK-M,
optional accessory including table stand and wireless
communication kit
Control unit communication ABB control unit protocol over EIA-485
3- phase monitoring ABB inverter to inverter (i2i) protocol over EIA-485
Remote monitoring communication Modbus RTU protocol over EIA-485
Remote monitoring adapter type SREA-50,
optional accessory including graphical user interface,
datalogger, Ethernet and GSM modem connectivity
Programmable relay output 2A, 30Vdc/250Vac, electrically isolated
Normally open or normally closed.
Source: 3AXD00000596478, 3AXD10000027043
