ABB REF615 - Page 122

Table 35: IEC 60870-5-103 settings
Parameter Values (Range) Unit Step Default Description
Serial port 1 0=Not in use
1=COM 1
2=COM 2
0=Not in use COM port for instance 1
Address 1 1...255 1 Unit address for instance 1
Start delay 1 0...20 char 4 Start frame delay in chars for
instance 1
End delay 1 0...20 char 4 End frame delay in chars for
instance 1
DevFunType 1 0...255 9 Device Function Type for instance
1
UsrFType 1 0...255 10 Function type for User Class 2
Frame for instance 1
UsrInfNo 1 0...255 230 Information Number for User
Class2 Frame for instance 1
Class1Priority 1 0=Ev High
1=Ev/DR Equal
2=DR High
0=Ev High Class 1 data sending priority
relationship between Events and
Disturbance Recorder data.
Frame1InUse 1 -1=Not in use
0=User frame
1=Standard frame 1
2=Standard frame 2
3=Standard frame 3
4=Standard frame 4
5=Standard frame 5
6=Private frame 6
7=Private frame 7
6=Private frame 6 Active Class2 Frame 1 for instance
1
Frame2InUse 1 -1=Not in use
0=User frame
1=Standard frame 1
2=Standard frame 2
3=Standard frame 3
4=Standard frame 4
5=Standard frame 5
6=Private frame 6
7=Private frame 7
-1=Not in use Active Class2 Frame 2 for instance
1
Frame3InUse 1 -1=Not in use
0=User frame
1=Standard frame 1
2=Standard frame 2
3=Standard frame 3
4=Standard frame 4
5=Standard frame 5
6=Private frame 6
7=Private frame 7
-1=Not in use Active Class2 Frame 3 for instance
1
Frame4InUse 1 -1=Not in use
0=User frame
1=Standard frame 1
2=Standard frame 2
3=Standard frame 3
4=Standard frame 4
5=Standard frame 5
6=Private frame 6
7=Private frame 7
-1=Not in use Active Class2 Frame 4 for instance
1
Table continues on next page
Section 4 1MRS756378 D
Basic functions
116 REF615
Application Manual
