Table 31: Ethernet front port settings
Parameter Values (Range) Unit Step Default Description
IP address 192.168.000.254 IP address for front port (fixed)
Mac address XX-XX-XX-XX-
XX-XX
Mac address for front port
Table 32: Ethernet rear port settings
Parameter Values (Range) Unit Step Default Description
IP address 192.168.002.010 IP address for rear port(s)
Subnet mask 255.255.255.000 Subnet mask for rear port(s)
Default gateway 192.168.002.001 Default gateway for rear port(s)
Mac address XX-XX-XX-XX-
XX-XX
Mac address for rear port(s)
Table 33: General system settings
Parameter Values (Range) Unit Step Default Description
Rated frequency 1=50Hz
2=60Hz
1=50Hz Rated frequency of the network
Phase rotation 1=ABC
2=ACB
1=ABC Phase rotation order
Blocking mode 1=Freeze timer
2=Block all
3=Block OPERATE
output
1=Freeze timer Behaviour for function BLOCK inputs
Bay name REF615 Bay name in system
SG follow input 0=False
1=True
0=False Enable setting group change to follow the input
state
Table 34: HMI settings
Parameter
Values (Range) Unit Step Default Description
FB naming convention 1=IEC61850
2=IEC60617
3=IEC-ANSI
1=IEC61850 FB naming convention used in IED
Default view 1=Measurements
2=Main menu
1=Measurements LHMI default view
Backlight timeout 1...60 min 1 3 LHMI backlight timeout
Web HMI mode 1=Active read only
2=Active
3=Disabled
3=Disabled Web HMI functionality
Web HMI timeout 1...60 min 1 3 Web HMI login timeout
