Table 37: MODBUS settings
Parameter Values (Range) Unit Step Default Description
Serial port 1 0=Not in use
1=COM 1
2=COM 2
0=Not in use COM port for Serial interface 1
Parity 1 0=none
1=odd
2=even
2=even Parity for Serial interface 1
Address 1 1...255 1 Modbus unit address on Serial interface 1
Link mode 1 1=RTU
2=ASCII
1=RTU Modbus link mode on Serial interface 1
Start delay 1 0...20 char 4 Start frame delay in chars on Serial interface 1
End delay 1 0...20 char 3 End frame delay in chars on Serial interface 1
Serial port 2 0=Not in use
1=COM 1
2=COM 2
0=Not in use COM port for Serial interface 2
Parity 2 0=none
1=odd
2=even
2=even Parity for Serial interface 2
Address 2 1...255 2 Modbus unit address on Serial interface 2
Link mode 2 1=RTU
2=ASCII
1=RTU Modbus link mode on Serial interface 2
Start delay 2 0...20 4 Start frame delay in chars on Serial interface 2
End delay 2 0...20 3 End frame delay in chars on Serial interface 2
MaxTCPClients 0...5 5 Maximum number of Modbus TCP/IP clients
TCPWriteAuthority 0=No clients
1=Reg. clients
2=All clients
2=All clients Write authority setting for Modbus TCP/IP clients
EventID 0=Address
1=UID
0=Address Event ID selection
TimeFormat 0=UTC
1=Local
1=Local Time format for Modbus time stamps
ClientIP1 000.000.000.000 Modbus Registered Client 1
ClientIP2 000.000.000.000 Modbus Registered Client 2
ClientIP3 000.000.000.000 Modbus Registered Client 3
ClientIP4 000.000.000.000 Modbus Registered Client 4
ClientIP5 000.000.000.000 Modbus Registered Client 5
CtlStructPWd1 **** Password for Modbus control struct 1
CtlStructPWd2 **** Password for Modbus control struct 2
CtlStructPWd3 **** Password for Modbus control struct 3
CtlStructPWd4 **** Password for Modbus control struct 4
CtlStructPWd5 **** Password for Modbus control struct 5
CtlStructPWd6 **** Password for Modbus control struct 6
Table continues on next page
