2.3.1.20 LD0.LLN0 Settings supervision
Table 23: LD0.LLN0 Settings supervision
IEC 61850 name SA name Description Values
LD0.LLN0
.SetChg.stVal - Settings changed 1=Changed
.SetSeld.stVal - Settings reserved 1=Reserved
2.3.1.21 LD0.LOFLPTUC1 Loss of load protection
Table 24: LD0.LOFLPTUC1 Loss of load protection
IEC 61850 name SA name Description Values
LD0.LOFLPTUC1
.Op.general OPERATE Stage operate 1=Operate
.Str.general START Stage start 1=Start
2.3.1.22 LD0.MAPGAPC1 Multipurpose analog protection function (1)
Table 25: LD0.MAPGAPC1 Multipurpose analog protection function (1)
IEC 61850 name
SA name Description Values
LD0.MAPGAPC1
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
2.3.1.23 LD0.MAPGAPC2 Multipurpose analog protection function (2)
Table 26: LD0.MAPGAPC2 Multipurpose analog protection function (2)
IEC 61850 name
SA name Description Values
LD0.MAPGAPC2
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
2.3.1.24 LD0.MAPGAPC3 Multipurpose analog protection function (3)
Table 27: LD0.MAPGAPC3 Multipurpose analog protection function (3)
IEC 61850 name
SA name Description Values
LD0.MAPGAPC3
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
1MRS756880 C Section 2
DNP3 data mappings
REM615 19
Point List Manual
