2.3.3.13 LD0.FMMXU1 Frequency measurement

Table 87: LD0.FMMXU1 Frequency measurement

IEC 61850 name SA name Description Values S Arg 1,2,3,4

LD0.FMMXU1

.Hz.mag - Frequency value 35…75 [Hz] R 35,75,3500,7500

2.3.3.14 CTRL.LLN0 Local remote station off

Table 88: CTRL.LLN0 Local remote station off

IEC 61850 name SA name Description Values S Arg 1,2,3,4

CTRL.LLN0

.LocRem.stVal -

Off=0; Loc=1; Rem=2;

Station=3 0…3 R 0,3,0,3

2.3.3.15 LD0.LPHD1 System values

Table 89: LD0.LPHD1 System values

IEC 61850 name

SA name Description Values S Arg 1,2,3,4

LD0.LPHD1

.NumCmpChg.stVal - Num.of comp. changes 0…65535 R 0,65535,0,65535

.NumPwrUp.stVal - Num.of power ups 0…65535 R 0,65535,0,65535

.PhyHealth1.stVal Warning Warning code 0…65535 R 0,65535,0,65535

.PhyHealth2.stVal Internal Fault Internal fault code 0…65535 R 0,65535,0,65535

.WacTrg.stVal - Num.of watchdog resets 0…65535 R 0,65535,0,65535

.WrmStr.stVal - Num.of warm starts 0…65535 R 0,65535,0,65535

2.3.3.16 LD0.MPTTR1 Thermal protection

Table 90: LD0.MPTTR1 Thermal protection

IEC 61850 name

SA name Description Values S Arg 1,2,3,4

LD0.MPTTR1

.TmpRl THERM_LEVEL Thermal level -99….999 R -99,999,-99,999

1MRS756880 C Section 2

DNP3 data mappings

REM615 35

Point List Manual
