ABB REM615 - LD0.VMMXU1 Voltage Measurement; LD0.VSMSQI1 Sequence of Voltage Measurement; LD0.XRGGIO130 RTD Inputs

2.3.3.21 LD0.VMMXU1 Voltage measurement
Table 95: LD0.VMMXU1 Voltage measurement
IEC 61850 name SA name Description Values S Arg 1,2,3,4
LD0.VMMXU1.PhV Phase-to-ground voltage
.phsA.cVal.mag U_DB_A -phsA magnitude
0.00…4.00
[xUn] R 0,4,0,400
.phsB.cVal.mag U_DB_B -phsB magnitude
0.00…4.00
[xUn] R 0,4,0,400
.phsC.cVal.mag U_DB_C -phsC magnitude
0.00…4.00
[xUn] R 0,4,0,400
LD0.VMMXU1.PPV Phase-to-phase voltage
.phsAB.cVal.mag U_DB_AB -phsAB magnitude
0.00…4.00
[xUn] R 0,4,0,400
.phsBC.cVal.mag U_DB_BC -phsBC magnitude
0.00…4.00
[xUn] R 0,4,0,400
.phsCA.cVal.mag U_DB_CA -phsCA magnitude
0.00…4.00
[xUn] R 0,4,0,400
2.3.3.22 LD0.VSMSQI1 Sequence of voltage measurement
Table 96: LD0.VSMSQI1 Sequence of voltage measurement
IEC 61850 name
SA name Description Values S Arg 1,2,3,4
LD0.VSMSQI1 Sequence of voltages
.SeqV.c1.cVal.mag I1_DB -Positive magnitude
0.00…4.00
[xUn] R 0,4,0,400
.SeqV.c2.cVal.mag I2_DB -Negative magnitude
0.00…4.00
[xUn] R 0,4,0,400
.SeqV.c3.cVal.mag I3_DB -Zero magnitude
0.00…4.00
[xUn] R 0,4,0,400
2.3.3.23 LD0.XRGGIO130 RTD inputs
Table 97: LD0.XRGGIO130 RTD inputs
IEC 61850 name
SA name Description Values S Arg 1,2,3,4
.AnIn1.instMag AI_VAL1 RTD input 1
-10000…
10000 R -1E4,1E4,-1E4,1E4
.AnIn2.instMag AI_VAL2 RTD input 2
-10000…
10000 R -1E4,1E4,-1E4,1E4
.AnIn3.instMag AI_VAL3 RTD input 3
-10000…
10000 R -1E4,1E4,-1E4,1E4
.AnIn4.instMag AI_VAL4 RTD input 4
-10000…
10000 R -1E4,1E4,-1E4,1E4
.AnIn5.instMag AI_VAL5 RTD input 5
-10000…
10000 R -1E4,1E4,-1E4,1E4
