2.3.1.43 LD0.SEQRFUF1 Fuse failure protection
Table 46: LD0.SEQRFUF1 Fuse failure protection
IEC 61850 name SA name Description Values
LD0.SEQRFUF1
.Str.general FUSEF_U General start 1=Start
.Str3Ph.general FUSEF_3PH Three-phase start 1=Start
2.3.1.44 LD0.SPCGGIO2 Multipurpose binary outputs - status (2)
Table 47: LD0.SPCGGIO2 Multipurpose binary outputs - status (2)
IEC 61850 name SA name Description Values
LD0.SPCGGIO2
.SPCS01.stVal - Output 1 state 0/1=Off/On
.SPCS02.stVal - Output 2 state 0/1=Off/On
.SPCS03.stVal - Output 3 state 0/1=Off/On
.SPCS04.stVal - Output 4 state 0/1=Off/On
.SPCS05.stVal - Output 5 state 0/1=Off/On
.SPCS06.stVal - Output 6 state 0/1=Off/On
.SPCS07.stVal - Output 7 state 0/1=Off/On
.SPCS08.stVal - Output 8 state 0/1=Off/On
.SPCS09.stVal - Output 9 state 0/1=Off/On
.SPCS10.stVal - Output 10 state 0/1=Off/On
.SPCS11.stVal - Output 11 state 0/1=Off/On
.SPCS12.stVal - Output 12 state 0/1=Off/On
.SPCS13.stVal - Output 13 state 0/1=Off/On
.SPCS14.stVal - Output 14 state 0/1=Off/On
.SPCS15.stVal - Output 15 state 0/1=Off/On
.SPCS16.stVal - Output 16 state 0/1=Off/On
2.3.1.45 LD0.SSCBR1 Circuit-breaker condition monitoring
Table 48: LD0.SSCBR1 Circuit-breaker condition monitoring
IEC 61850 name
SA name Description Values
.APwrAlm.stVal IPOW_ALM Iyt alarm 1=Alarm
.APwrLO.stVal IPOW_LO Iyt lockout 1=Lockout
.CBLifAlm.stVal CB_LIFE_ALM CB lifetime alarm 1=Alarm
.ClsAlm.stVal TRV_T_CL_ALM Cls travel time alarm 1=Alarm
.LonTmAlm.stVal MON_ALM CB inactive alarm 1=Alarm
.OpnAlm.stVal TRV_T_OP_ALM Cls travel time alarm 1=Alarm
Table continues on next page
Section 2 1MRS756880 C
DNP3 data mappings
24 REM615
Point List Manual
