ABB RMC-100 - Enclosures; Table 2-2: Xcore Enclosures Available

14 | RMC-100| 2105552MNAE
Characteristic
Display
Character font size
8 x 6 pixels
Number of items displayed at one time
2 items (each item uses 2 lines to display)
Annunciator font size
16 x 12 pixels
Annunciator position
Lines 7 and 8
Annunciator position control
Fixed
Annunciator and plots
Displays both at the same time
Number of plots displayed at one time
2
Each display item has two lines as the data scrolls up the screen. The name of the item is on the first
line. The measurement value and unit display on the second line. A blank line displays between the
two items. The plot for the item displays on the right side of the display.
Figure 2-3: LCD Display
Four directional buttons control and display items from the LCD interface. The button directions are:
up, down, left (previous) and right (next). Use the up and down buttons to view individual display
items for a display group. Use the left and right buttons to view the display groups. By default, the
first annunciator displays the selected group. The directional buttons do not allow any data entry.
2.1.2 Enclosures
The RMC can be purchased already installed in an enclosure. ABB offers the Xcore enclosures
described in Table 2-2
. For more information and complete specifications see
www.abb.com/upstream.
Table 2-2: Xcore enclosures available
Part number
Size
Weight
2424
24 x 24 x 12 inches (61 x 61 x 30 cm)
45 pounds maximum
(Fully loaded system)
3630
36 x 30 x 12 inches (91 x 76 x 30 cm)
75 pounds maximum
(Fully loaded system)
DATE/TIME
02/28/16 13:00:26
Annunciators
NAME
DATA UNITS
