38 | RMC-100| 2105552MNAE

Figure 3-10: Connecting multiple RMCs

Figure 3-11

illustrates how an Ethernet port supports connecting other ABB equipment.

TCP/IP

netw ork

Hos t

System

With

PCCU

Ethernet 1

Ethernet 2

RMC 1

RMC 2

RMC 3
