14 SCU200 INSITE ENERGY MANAGEMENT SYSTEM
N L1
2.4.Power supply modules
• LED
Display Function
Off Device is off
Green on Device is on
Green flashing fast N/A
Green flashing slowly N/A
Modular bus
connector (input)
Modular bus
connector (output)
Status LED
AC power input
FRONT VIEW
TOP VIEW
LATERAL VIEW
