ABB SCU200 - USB Module

17SCU200 INSITE ENERGY MANAGEMENT SYSTEM
2.6.2.USB module
• LED status
Display Function
Off Device is off
Green on Device is ON
• LED USB
Display
Function
Green on USB bus is ready for operation
Red on USB ports error (e.g. port overcurrent, lack of connection with SCU200)
Modular bus
connector
(output)
Modular bus
connector
(output)
Modular bus
connector
(output)
Status LED
Connection LED
Bottom USB-A port
(general purpose)
Top USB-A port
(P1 port)
FRONT VIEW
TOP VIEW
LATERAL VIEWS
BOTTOM VIEW
