26
87
17,5
65
SCU200 INSITE ENERGY MANAGEMENT SYSTEM
3.3.4.USB module
Technical feature Unit Description
Supply voltage [VDC] Supplied by the InSite modular bus
Connection InSite modular bus
Power consumption [W] 0.4 (standby)
Communication protocol USB 1.1 (max speed 12Mbps)
Power capabilities
100mA @5V (USB P1 port)
500mA @5V (bottom USB port)
Mounting method 35mm DIN rail (DIN 5022)
Degree of protection IP20
Dimensions [mm] 17.5x87x65 (1M)
Weight [g] 46
Operating temperature [°C] -25... +60
Storage temperature [°C] -40... +85
Operating altitude [m] 0… 2000
Standards
IEC 61010-1
IEC 61326-1
