ABB Uvisor SF910i - Page 18

Table: Compatibility with Previous Products
SF910i Part NumberCompatibilityPart NumberPrevious Models
SF910i -LOS-IR-X
(1)
-
(2)
-
(3)
YesPart number
EC-BOM-G009HLA101 +
EC-BOM-G009HLA012
One UR600-IR (Line Of
Sight) + MFD
SF910i -FOC-IR-X
(1)
-
(2)
-
(3)
Yes (External guide pipe is
compatible, inner fiber is
not)
EC-BOM-G009HLA101 +
86610-S-210XXXX +
EC-BOM-G009HLA012
One UR600-IR (Fiber Optic
Cable) + MFD
SF910i -LOS-UV-X
(1)
-
(2)
-
(3)
YesEC-BOM-G009HLA102 +
EC-BOM-G009HLA012
One UR600-UV (Line Of
Sight) + MFD
SF910i -LOS-UV-X
(1)
-
(2)
-
(3)
Yes (Extended guide pipe
is compatible, inner fiber is
not)
EC-BOM-G009HLA103+
86610-S-220XXXX +
EC-BOM-G009HLA012
One UR600-UVEXT (Fiber
Optic Cable) + MFD
SF910i -LOS-UV-X
(1)
-
(2)
-
(3)
Yes (Requires adapting
flange)
EC-BOM-G009HLA002 +
EC-BOM-G009HLA012
One UR450 + MFD
SF910i -LOS-UV-X
(1)
-
(2)
-
(3)
Yes (Requires adapting
flange)
EC-BOM-G009HLA004
84531-S-3300000 +
EC-BOM-G009HLA012
One UR460 (Direct View)
+MFD
SF910i -LOS-UV-X
(1)
-
(2)
-
(3)
Yes (Extended guide pipe
is compatible, inner fiber is
not)
EC-BOM-G009HLA004
84531-S-3280000 or
84531-S-3290000 +
EC-BOM-G009HLA012
One UR460 (Fiber Optic
Cable) + MFD
SF910i -LOS-UV-X
(1)
-
(2)
-
(3)
Yes (Requires mechanical
adapter plus change of
connector in the existing
cable)
C10-97335 + C10-11010One SafeFlame
Wall-mount UV scanner,
cam lock + FAU800
SF910i -FOC-IR-X
(1)
-
(2)
-
(3)
Yes (Existing guide pipe is
compatible, requires flange
adapter)
C10-922xxx + C10-11010One SafeFlame IR (or full
spectrum) scanner
(through the wind box, cam
lock, FOC) + FAU800
(1). See Table 1.1 for the meaning of all suffixes of the part number.
(2). Owing to the change of architecture when replacing the existing scanners and analysis units with a single “integrated” unit,
it requires wiring changes.
(3). Both connectorized versions need a wiring change too. The new connector is not compatible with the previous SafeFlame
Scanner connector to be replaced. Refer to Table 3.2.
8VZZ005286 B 18
About This User Manual
Compatibility with Previous ABB Flame Detection Products
