Abov MC96F6432Q User Manual

MC96F6432
178 June 22, 2018 Ver. 2.9
T4PCR2 (Timer 4 PWM Control Register 2) : 1004H (ESFR)
7
6
5
4
3
2
1
0
FORCA
–
PAAOE
PABOE
PBAOE
PBBOE
PCAOE
PCBOE
R/W
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
FORCA
Control The PWM outputs Mode
0
6-channel mode
(The PWM4xA/PWM4xB pins are output according to the
T4xDR registers, respectively. Where x = A, B and C)
1
Force A-channel mode
(The all PWM4xA/PWM4xB pins are output according to the
only T4ADR registers. Where x = A, B and C)
PAAOE
Select Channel PWM4AA Operation
0
Disable PWM4AA output
1
Enable PWM4AA output
PABOE
Select Channel PWM4AB Operation
0
Disable PWM4AB output
1
Enable PWM4AB output
PBAOE
Select Channel PWM4BA Operation
0
Disable PWM4BA output
1
Enable PWM4BA output
PBBOE
Select Channel PWM4BB Operation
0
Disable PWM4BB output
1
Enable PWM4BB output
PCAOE
Select Channel PWM4CA Operation
0
Disable PWM4CA output
1
Enable PWM4CA output
PCBOE
Select Channel PWM4CB Operation
0
Disable PWM4CB output
1
Enable PWM4CB output
