USI0CR1 (USI0 Control Register 1: For UART, SPI, and I2C mode) : D9H
7
6
5
4
3
2
1
0
USI0MS1
USI0MS0
USI0PM1
USI0PM0
USI0S2
USI0S1
ORD0
USI0S0
CPHA0
CPOL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
USI0MS[1:0]
Selects operation mode of USI0
USI0MS1
USI0MS0
Operation mode
0
0
Asynchronous Mode (UART)
0
1
Synchronous Mode
1
0
I2C mode
1
1
SPI mode
USI0PM[1:0]
Selects parity generation and check methods (only UART mode)
USI0PM1
USI0PM0
Parity
0
0
No Parity
0
1
Reserved
1
0
Even Parity
1
1
Odd Parity
USI0S[2:0]
When in asynchronous or synchronous mode of operation,
selects the length of data bits in frame
USI0S2
USI0S1
USI0S0
Data Length
0
0
0
5 bit
0
0
1
6 bit
0
1
0
7 bit
0
1
1
8 bit
1
0
0
Reserved
1
0
1
Reserved
1
1
0
Reserved
1
1
1
9 bit
ORD0
This bit in the same bit position with USI0S1. The MSB of the data
byte is transmitted first when set to ‘1’ and the LSB when set to ‘0’
(only SPI mode)
0
LSB-first
1
MSB-first
CPHA0
This bit is in the same bit position with USI0S0. This bit determines if
data are sampled on the leading or trailing edge of SCK0 (only SPI
mode).
CPOL0
CPHA0
Leading edge
Trailing edge
0
0
Sample (Rising)
Setup (Falling)
0
1
Setup (Rising)
Sample (Falling)
1
0
Sample (Falling)
Setup (Rising)
1
1
Setup (Falling)
Sample (Rising)
CPOL0
This bit determines the clock polarity of ACK in synchronous or SPI
mode.
0
TXD change@Rising Edge, RXD change@Falling Edge
1
TXD change@Falling Edge, RXD change@Rising Edge
