Abus HDCC90000 - Video Tampering

Camera
38
Up to four private zones can be defined per camera.
These are created by drawing the zones with the mouse
in the preview image.
Using "Clear All", all zones are reset simultaneously.
Alternatively, the zones can be cleared individually with
the buttons.
Video Tampering
Select the camera channel to be processed under
"Camera".
Tick the "Enable Video Tampering Detection" box and
define any other optional parameters under "Settings".
The sabotage alarm is activated if there is any tampering
with the camera lens (sharpness, dimming).
Arming Schedule
Select the Arming Schedule tab.
Here you set the times at which the reactions set in the
Linkage Action tab are triggered.
1. Select the day and enter the schedule.
Note
You can define up to eight time slots, between
00:00 and 00:00 in each case, but the individual
time slots must not overlap.
2. Under Copy, select whether or not the setting should
be applied to every day of the week and the holiday
settings.
3. Confirm the settings by clicking on Apply and exit
the menu by clicking on OK.
Linkage Action
Select the Linkage Action tab.
Here you can configure the response of the recorder
during an event (e.g. motion detected) by ticking the
corresponding box.
Parameter
Notifications
Full Screen Monitoring
The camera is displayed in
full screen in live view.
Audible Warning
The device emits a
repeated signal tone.
Notify Surveillance
Center
The CMS sends out a
warning message.
Send Email
An email is sent to a
specified email address.
See page 29.
Trigger Alarm Output
The alarm output is
triggered in the event of an
alarm.
Confirm the settings by clicking on Apply and exit the
menu by clicking on OK.
