System operation
4
System operation
General
The device can be controlled using the following:
 Control panel on the front of the device
 a USB mouse
Connections at the back of the device
Note
Take a look at the overview on page 3.
No
Name
Function
1
AUDIO IN
 4 Audio cinch inputs
2
VIDEO OUT
 Spot output
3
VGA:
 VGA monitor connection (9-pin), video output
signal
4
LAN:
 Ethernet LAN connection
5
USB:
 USB connections for operating with a mouse
and data export
6
HDMI
 HDMI monitor connection
7
AUDIO OUT:
 BNC audio output (synchronised with the
video output)
8
POWER SUPPLY
 100–240 V AC connection for power supply
9
ALARM IN/OUT
 16 alarm inputs/4 alarm outputs
10
RS-485
 Connection for pan tilt zoom (PTZ) cameras
11
JOG DIAL
 For selecting the operating mode
12
VIDEO IN:
 BNC input for HD-TVI and analogue
cameras
13
LINE IN
 Audio input for 2-way communication
Operating with a mouse
Note
The further descriptions contained in this user
guide involve using a mouse.
The device is suitable for use with a USB mouse.
Connect the mouse to the USB port.
Button
Function
Left
Single click:
 Selection in the menu, activation of an input
field or a tab, display of the Quick Set
menu.
Double click:
 Switch between the screen display of single
and multiple images in the live view and
during playback.
Click and drag:
 Set up private masks or zones.
Right
Single click:
 Open the pop-up menu.
 Return to the previous menu.
Scroll
wheel
In live view:
 Display previous/next camera.
