Fieldbus Interface
106
Output Array data format – detailed description:
Output Array Word 0, Bytes 0 and 1 - Operating Mode Command
Byte Bit Function Value Action Performed
0
7 Auto
1 Select Automatic mode.
0 No change.
6
Servo
Center
1 Select Servo-Center mode (move actuator to Servo-Center position).
0 No change.
5 Manual
1 Select Manual mode (stop actuator).
0 No change.
4 In
1 Select Manual mode and In mode (move actuator in).
0 No change.
3 Out
1 Select Manual mode and Out mode (move actuator out).
0 No change.
2 Input A
1 Select Input A.
0 No change.
1 Input B
1 Select Input B.
0 No change.
0 Centerline
1 Select Input A and Input B for centerline guiding with two detectors.
0 No change.
