Fieldbus Interface
111
Input Array Word 0, Byte 1 - Operating Mode Status
Bit Function Value Status Indicated
7 Auto
1 The unit is in Automatic mode.
0 This mode not selected.
6 Servo Center
1 The unit is in Servo-Center mode.
0 This mode not selected.
5 Manual
1 The unit is in Manual mode.
0 This mode not selected.
4 In
1 The unit is in Manual mode and the In command is active.
0 This mode not selected.
3 Out
1 The unit is in Manual mode and the Out command is active.
0 This mode not selected.
2 Input A
1 Input A is selected.
0 This mode not selected.
1 Input B
1 Input B is selected.
0 This mode not selected.
0 Centerline (2 detectors)
1 Centerline mode (2 detectors) is selected.
0 This mode not selected.
Input Array Word 1, Bytes 2 and 3 - Actuator Position
Byte Value Status Indicated
2
Lower byte
0-255 [0-FFh]
This 16-bit value indicates the current actuator position.
Refer to Table 2 on page 60 for the range of allowed values.
3
Upper byte
0-255 [0-FFh]
Input Array Word 2, Bytes 4 and 5 - Edge A Position
Byte Value Status Indicated
4
Lower byte
0-255 [0-FFh]
This 16-bit value indicates the current position of the web in sensor A.
Refer to Table 1 on page 59 for the range of allowed values.
5
Upper byte
0-255 [0-FFh]
