EVO 150 Controller
23
Auto-Mode Speed Limit
7 8 0
This parameter limits the top speed of the actuator in Automatic mode.
The higher this value is set, the faster the actuator can move. The
default value is 80.
Range: 0 to 120
Note: This value is set by the Controller Settings Screen button.
Manual-Mode Speed
8 8 0
This parameter determines how fast the actuator will move in Manual
and Servo-Center mode. The higher this value is set, the faster the
actuator will move. The default value is 80.
Range: 0 to 120
In End-of-Travel Limit
9 6 7
This parameter works only with actuators that have potentiomete
feedback (TA, MTB, SFB, MT, SF, HF and MA). It sets the maximum
distance that the actuator can move In. To increase this distance, set this
parameter to a lower value. The default value is 67.
Important: Refer to page 84 for minimum and maximum values.
Note: Use the Actuator Setting Screen to examine the current actuato
position value.
Range: 0 to 255
Note: This value is set by the Actuator Settings Screen button.
Out End-of-Travel Limit
1 0 1 8 9
This parameter works only with actuators that have potentiomete
feedback (TA, MTB, SFB, MT, SF, HF and MA). It sets the maximum
distance that the actuator can move Out. To increase this distance, se
this parameter to a higher value. The default value is 189.
Important: Refer to page 84 for minimum and maximum values.
Note: Use the Actuator Setting Screen to examine the current actuato
position value.
Range: 0 to 255
Note: This value is set by the Actuator Settings Screen button.
Servo-Center Position
1 1 1 2 8
This parameter works only with actuators that have potentiomete
feedback (MT, SF, and HF). It sets the home position for the actuato
when Servo-Center mode is selected. To move the servo-center position
closer to the In limit, set this parameter to a lower value. To move the
servo-center position closer to the Out limit, set this parameter to a
higher value. The default value is 128.
Important: Refer to page 84 for minimum and maximum values.
Note: Use the Actuator Setting Screen to examine the current actuato
position value.
Range: 0 to 255
Note: This value is set by the Actuator Settings Screen button.
