EVO 150 Controller
24
Input A Type
1 2 0
Sensor A is not installed.
1 2 1
Sensor A is an ultrasonic or IR edge detector connected to the Edge
Detector A input. This is the default setting.
Note: Set parameter 55 to select sensor type.
1 2 2
Sensor A is a digital line guide connected to the Serial I/O board.
Note: This value is set by the Setting Screen Edge Detector Settings button.
Input B Type
1 3 0
Sensor B is not installed. This is the default setting.
1 3 1
Sensor B is an ultrasonic or IR edge detector connected to the Edge
Detector B input.
Note: Set parameter 56 to select sensor type.
1 3 2
Sensor B is a digital line guide connected to the Serial I/O board.
Note: This value is set by the Setting Screen Edge Detector Settings button.
Parameters 14 through 17 have not yet been implemented.
Minimum Deadband
1 8 5
The minimum deadband is a zone around the sensor guide point that the
web edge or line must enter before the motor drive is turned off. Once
the web edge or line position enters this zone, it must then move outside
of the maximum deadband zone before the motor drive is turned on. The
Minimum Deadband value must be lower than the Maximum Deadband
value. The default value is 5.
Range: 0 to 100
INHIBIT Input Mode
Refer to page 46 for more information about the INHIBIT input.
1 9 0
The actuator will run only if the INHIBIT input is activated. The INHIBIT
input controls the actuator in Automatic, Manual, or Servo-Center mode.
1 9 1
Same function as option 0, except the polarity of the INHIBIT input is
inverted. This is the default setting.
1 9 2
The actuator will run only if the INHIBIT input is activated. The INHIBIT
input controls the actuator only in Automatic mode.
1 9 3
Same function as option 2, except the polarity of the INHIBIT input is
inverted.
Note: If your application requires an opto-isolated INHIBIT input, then set parameter 72 to 1.
