EVO 150 Controller
25
Parameters 20 through 23 have not yet been implemented.
Sensor A Length
2 4 2
This parameter configures the system for the number of sensing beams
in sensor A. The default value is 2.
This parameter is automatic set when
Refer to the table of sensor models on page 56.
To reduce the sensing area of a WideArray detector, change paramete
r
76.
Range: 2 to 128
Note: This value is set by the Setting Screen Edge Detector Settings button.
Sensor B Length
2 5 2
This parameter configures the system for the number of sensing beams
in sensor B. The default value is 2.
Refer to the table of sensor models on page 56.
To reduce the sensing area of a WideArray detector, change paramete
r
77.
Range: 2 to 128
Note: This value is set by the Setting Screen Edge Detector Settings button.
Actuator Position Display
This parameter displays the position of the actuator. The display format depends on the type of
actuator installed:
2 6 0
A
ctuators with potentiometer feedback
(
TA, MTB, SFB, MT, SF, HF and
MA). The data display indicates the position of the actuator’s end-of-
travel potentiometer.
Range: 0 to 255
Note: This parameter only displays the current position of the actuator with potentiometer upon
viewing the parameter.
Use the Actuator Setting Screen to examine a dynamic current actuator position value.
Power-Up Mode
2 7 0
The system will power-up in the same operating mode that was selected
when last powered-down. All inputs are momentary. This is the default
setting.
