EVO 150 Controller
29
AUXILIARY Input Function
Refer to page 47 for more information about the AUXILIARY input.
5 2 0
The AUXILIARY input is off. This is the default setting.
5 2 1
The AUXILIARY input determines which offset is active. To select Offse
2, activate the AUXILIARY input. To select Offset 1, deactivate the
AUXILIARY input.
5 2 2
Same function as option 1, except the polarity of the AUXILIARY input is
inverted.
5 2 3
ctivating the AUXILIARY input will enable Oscillation, and deactivating
it will disable Oscillation. Oscillation parameter 31 must be set to 1 o
higher.
Refer to page 44 for more information about the oscillation function.
5 2 4
Same function as option 3, except the polarity of the AUXILIARY input is
inverted.
5 2 5
Activating the AUXILIARY input will switch the system to Automatic
mode.
5 2 6
Same function as option 5, except the polarity of the AUXILIARY input is
inverted.
5 2 7
ctivating the AUXILIARY input will set Offset 1 to the current web
position. This is typically done only during job set-up, when the system is
in Manual or Servo-Center mode.
Note: To reset Offset 1 to its default value, select parameter 60, then
press the EXIT key.
5 2 8
Same function as option 7, except the polarity of the AUXILIARY input is
inverted.
5 2 9
ctivating the AUXILIARY input will set Offset 2 to the integrator’s inpu
value and will reset the integrator output. This is typically done only
during job set-up, when the system is in Manual or Servo-Center mode.
Note: To reset Offset 2 to its default value, select parameter 61, then
press the EXIT key.
5 2 1 0
Same function as option 9, except the polarity of the AUXILIARY input is
inverted.
5 2 1 1
Activating the AUXILIARY input will switch the system to Servo-Cente
mode. The system will return to the previous operating mode when the
AUXILIARY input is deactivated.
5 2 1 2
Same function as option 11, except the polarity of the AUXILIARY input
is inverted.
5 2 1 3
Activating the AUXILIARY input will switch the system to Servo-Cente
mode. The system will remain in Servo-Center mode when the
AUXILIARY input is deactivated.
[continued on next page]
