AccuWeb EVO 150 - Page 33

EVO 150 Controller
31
Integrator Mode
6 3 0
The integrator function is off. This is the default setting.
6 3 1
This mode is used for applications that require complex control of the
system guide point, but without integration or dampening.
6 3 2
This mode is used for stabilizing the response of guides that have
sensors located downstream. The downstream sensors are connected to
Integrator Input 1 and 2 and the local sensors are connected to Input A,
and B. During operation the integrator output slowly changes the local
guide point as long as the downstream sensors indicate that the web is
not at the downstream guide point.
6 3 3
This mode is used for dampening the response of the slave guide in
chaser-slave systems. The chaser sensors are connected to Integrato
r
Input 1 and 2 and the slave sensors are connected to Input A and B.
During operation the chaser sensors establish the slave guide point, but
the integrator dampens noise and jitter in the chaser signal.
Integrator Input 1 Type
This parameter selects the source for Integrator Input 1.
6 4 0
No input (zero).
6 4 1
Sensor 1.
6 4 2
Sensor 2. This is the default setting.
6 4 3
Digital line guide.
Integrator Input 2 Type
This parameter selects the source for Integrator Input 2.
6 5 0
No input (zero). This is the default setting.
6 5 1
Sensor 1.
6 5 2
Sensor 2.
6 5 3
Digital line guide.
