EVO 150 Controller
38
36 Sensor A gap 0-2 1
37 Sensor B gap 0-2 1
38 not used - - -
not used
39 not used - - -
not used
40 not used - - -
not used
41 not used - - -
not used
42 not used - - -
not used
43 not used - - -
not used
44 not used - - -
not used
45 not used - - -
not used
46 not used - - -
not used
47 Edge-loss detection 0-1 0
48 Servo gain and speed limit source 0-1 0
49 Input C type 0-2 0
50 Input C polarity 0-1 0
51 not used - - -
see note 1
52 AUXILIARY input function 0-14 0
53 Oscillation minimum speed - - -
not used
54 not used - - -
not used
55 Sensor A type 0, 1 0
56 Sensor B type 0, 1 0
57 not used - - -
not used
58 not used - - -
not used
59 not used - - -
not used
60 Offset 1 - - -
see note 1
61 Offset 2 - - -
see note 1
62 Manual polarity 0, 1 1
63 Integrator mode 0-3 0
64 Integrator input 1 type 0-3 2
65 Integrator input 2 type 0-3 0
66 Integrator input 1 polarity 0, 1 0
67 Integrator input 2 polarity 0, 1 0
68 Integrator rate .001-.255 .010
69 Integrator rate limit .01-1.00 1.00
70 Integrator input gain 0, 1 0
