AccuWeb EVO 150 - Appendix 3; Centerline Guiding with One Detector

EVO 150 Controller
39
71 Integrator input offset 0, 1 0
72 AUXILIARY and INHIBIT input config 0, 1 0
73 not used - - -
not used
74 Sensor A transducer orientation 0, 1 0
75 Sensor B transducer orientation 0, 1 0
76 Sensor A reduced length 2-128 2
77 Sensor B reduced length 2-128 2
78 Fieldbus Swap Bytes 0, 1 1
79 View register item - - -
see note 1
80 Register item - - -
see note 1
81 Rest parameters - - -
see note 1
82 Units - - -
see note 1
83 Maximum Motor Current 1-30 15
84 Motor Direction Byte 1, 2 1
85 Fieldbus Enable Bit 0, 1 0
86 Web Server IP Address – 1
st
Octet 0-255 192
87 Web Server IP Address – 2
nd
Octet 0-255 168
88 Web Server IP Address – 3
rd
Octet 0-255 0
89 Web Server IP Address – 4
th
Octet 0-255 8
90 Web Server Subnet Mask – 1
st
Octet 0-255 255
91 Web Server Subnet Mask – 2
nd
Octet 0-255 255
92 Web Server Subnet Mask – 3
rd
Octet 0-255 255
93 Web Server Subnet Mask – 4
th
Octet 0-255 0
94 Web Server Gateway – 1
st
Octet 0-255 192
95 Web Server Gateway – 2
nd
Octet 0-255 168
96 Web Server Gateway – 3
rd
Octet 0-255 0
97 Web Server Gateway – 4
th
Octet 0-255 1
98 Centerline Mode 0 - 3 0
1
Not yet implemented.
2
These parameters are used for monitoring system functions and cannot be changed through the
parameter entry button.
