AccuBeam 3 Digital Line Guide Sensor
75
Backlight
B a c k l i g h t O N
This parameter controls the LCD display backlight.
The default value is on.
B a c k l i g h t O F F
Start-Up
S t a r t - U p 1 8
This parameter determines which parameter will be
displayed first when the Digital Line Guide is powered-up.
Refer to the table below for the numeric code that
corresponds to each parameter.
The default value is 18 (Job Profile).
Range: 0 to 18
Parameter
Start-Up
Value
Job Profile 18
Offset 17
Calibrate 16
LED Color 15
LED Angle 14
Filter 13
Threshold 12
Pattern 11
Scan Direction 10
Maximum Left 9
Minimum Left 8
Maximum Center 7
Minimum Center 6
Maximum Right 5
Minimum Right 4
Backlight 3
Hidden 2
Read-Only 1
Start-Up 0
