AccuBeam 3 Digital Line Guide Sensor
74
Maximum Center (Tracking Parameter)
M a x C e n t e r 1 2 7
This parameter specifies the maximum acceptable width o
f
the registration line. This parameter is not used when
tracking an edge. The default value is 127.
Range: 0 to 127 half-pixels
Note: A setting of 127 disables this Min/Max rule.
Note: A “pixel” is equivalent to 0.0049” [0.124mm].
Minimum Center (Tracking Parameter)
M i n C e n t e r 0
This parameter specifies the minimum acceptable width o
f
the registration line. This parameter is not used when
tracking an edge. The default value is 0.
Range: 0 to 127 pixels
Note: A setting of 0 disables this Min/Max rule.
Note: A “pixel” is equivalent to 0.0049” [0.124mm].
Maximum Right (Tracking Parameter)
M a x R i g h t 1 2 7
This parameter specifies the maximum acceptable width o
f
the area located to the right of the registration line or edge.
The default value is 127.
Range: 0 to 127 half-pixels
Note: A setting of 127 disables this Min/Max rule.
Note: A “pixel” is equivalent to 0.0049” [0.124mm].
Minimum Right (Tracking Parameter)
M i n R i g h t 0
This parameter specifies the minimum acceptable width o
f
the area located to the right of the registration line or edge.
The default value is 0.
Range: 0 to 127 pixels
Note: A setting of 0 disables this Min/Max rule.
Note: A “pixel” is equivalent to 0.0049” [0.124mm].
