AccuBeam 3 Digital Line Guide Sensor
73
Pattern (Tracking Parameter)
P A t t e r n L t - D k - L t
Light-Dark-Light: This setting will cause the sensor to track
a dark line printed on a light background. This is the
default value.
P A t t e r n D k - L t - D k
Dark-Light-Dark: This setting will cause the sensor to track
a light line printed on a dark background.
P A t t e r n L t - D k
Light-Dark: This setting will cause the sensor to track the
left edge of a dark line or stripe printed on a light
background, or the right edge of a light line or stripe
printed on a dark background.
P A t t e r n D k - L t
Dark-Light: This setting will cause the sensor to track the
right edge of a dark line or stripe printed on a light
background, or the left edge of a light line or stripe printed
on a dark background.
Scan Direction (Tracking Parameter)
S C a n D i r R - t o - L
Right-to-Left: Scan the pattern from right to left. The
sensor will evaluate objects in its field of view beginning
with those on the far right. This is the default value.
S C a n D i r L - t o - R
Left-to-Right: Scan the pattern from left to right. The
sensor will evaluate objects in its field of view beginning
with those on the far left.
Maximum Left (Tracking Parameter)
M A x L e f t 1 2 7
This parameter specifies the maximum acceptable width o
the area located to the left of the registration line or edge.
The default value is 127.
Range: 0 to 127 pixels
Note: A setting of 127 disables this Min/Max rule.
Note: A “pixel” is equivalent to 0.0049” [0.124mm].
Minimum Left (Tracking Parameter)
M I n L e f t 0
This parameter specifies the minimum acceptable width o
the area located to the left of the registration line or edge.
The default value is 0.
Range: 0 to 127 pixels
Note: A setting of 0 disables this Min/Max rule.
Note: A “pixel” is equivalent to 0.0049” [0.124mm].
