Input Array byte 1 Operating Mode Status – continued
Bit Function Value Status Indicated
Parameter 51 (Switchpad Mode) is set to 0:
Centerline mode is selected.
Parameter 51 (Switchpad Mode) is set to 1:
Input C is selected.
Input C
1
0
or
Parameter 51 (Switchpad Mode) is set to 2:
Input C is selected and the unit is in Automatic mode.
Centerline
0 This mode not selected.
Input Array bytes 2 and 3 Actuator Position
Byte Value Status Indicated
Low byte
2
0-255 [0-FFh]
This 16-bit value indicates the current actuator position.
High byte
Refer to Table 2 on page 115 for the range of allowed values.
3
0-255 [0-FFh]
Input Array bytes 4 and 5 Edge A Position
Byte Value Status Indicated
Low byte
4
0-255 [0-FFh]
This 16-bit value indicates the current position of the web in sensor A.
High byte
Refer to Table 1 on page 114 for the range of allowed values.
5
0-255 [0-FFh]
Input Array bytes 6 and 7 Edge B Position
Byte Value Status Indicated
Low byte
6
0-255 [0-FFh]
This 16-bit value indicates the current position of the web in sensor B.
High byte
Refer to Table 1 on page 114 for the range of allowed values.
7
0-255 [0-FFh]
Fieldbus Interface
113
