Input Array byte 1 Operating Mode Status
Bit Function Value Status Indicated
Parameter 51 (Switchpad Mode) is set to 0 or 1:
Not defined.
1
Parameter 51 (Switchpad Mode) is set to 2:
The unit is in Automatic mode.
7 Auto
0 This mode not selected.
1 The unit is in Servo-Center mode.
Servo
Center
6
0 This mode not selected.
1 The unit is in Manual mode.
5 Manual
0 This mode not selected.
1 The unit is in Manual mode and the In command is active.
4 In
0 This mode not selected.
1 The unit is in Manual mode and the Out command is active.
3 Out
0 This mode not selected.
Parameter 51 (Switchpad Mode) is set to 0 or 1:
Input A is selected
Parameter 51 (Switchpad Mode) is set to 2:
1
Input A is selected and the unit is in Automatic mode.
Note: If the I
nput A and B status bits are both set to 1, then the unit is
in Centerline mode.
2 Input A
0 This mode not selected.
Parameter 51 (Switchpad Mode) is set to 0 or 1:
Input B is selected
Parameter 51 (Switchpad Mode) is set to 2:
1
Input B is selected and the unit is in Automatic mode.
Note: If the Input A and B
status bits are both set to 1, then the unit is
in Centerline mode.
1 Input B
0 This mode not selected.
Fieldbus Interface
112
