Input Array data format – detailed description:
Input Array byte 0 Actuator Status
Bit Function Value Status Indicated
1 The actuator has retracted to the In limit position.
7 In Limit
0 The actuator is not at the In limit position.
1 The actuator has extended to the Out limit position.
6 Out Limit
0 The actuator is not at the Out limit position.
1 The actuator has reached the Servo-Center position.
Servo
Center
5
0 The actuator is not at the Servo-Center position.
4 not used x none
1 The controller is operating correctly. There are no operating faults.
The controller is not operating correctly. Check the flashing ‘99’ error
code on the controller’s parameter-entry display. Refer to page 42 for
more info
rmation about error codes.
3 No Fault
0
or
An edge-loss or line-loss condition has occurred. This option is
enabl
ed by setting parameter 47. Refer to page 17 for more
informatio
n about setting controller parameters.
2 not used x none
1 not used x none
0 not used x none
Fieldbus Interface
111
